Floor-standing bidet CAD block · front & side
1′-6⅝″472 mm
2′-8⅝″830 mm
Front elevation · 18⅝″ × 32⅝″472 × 830 mm · next to a 6 ft (1,829 mm) person
1′-4⅞″430 mm
2′-8⅝″830 mm
Side elevation · 16⅞″ × 32⅝″430 × 830 mm · next to a 6 ft (1,829 mm) person
Description
This page brings together 2 drawings of the floor-standing bidet: a front elevation at 18⅝″ wide and 32⅝″ high (472 × 830 mm) and a side elevation at 16⅞″ deep and 32⅝″ high (430 × 830 mm).
In the 30″ (762 mm) width the IRC asks for, its 18⅝″ leaves 5¾″ (145 mm) on each side. Under the IRC it needs a space 30″ (762 mm) wide, 15″ (381 mm) each side of its centerline, and 37⅞″ (963 mm) deep: its own 16⅞″ plus 21″ (533 mm) clear in front.
It is a simple drawing: 128 curves.
Common questions
How big is the floor-standing bidet in each view?
The front elevation measures 18⅝″ wide and 32⅝″ high (472 × 830 mm); the side elevation measures 16⅞″ deep and 32⅝″ high (430 × 830 mm). Each size is taken from the outer edges of that drawing.
How much space does the floor-standing bidet need?
A space at least 30″ (762 mm) wide and 37⅞″ (963 mm) deep: 15″ (381 mm) from its centerline to each side, and 21″ (533 mm) of clear floor in front of its 16⅞″ depth (IRC R307).
Is the floor-standing bidet drawing simple or detailed?
It is a simple drawing: 128 curves.
